Thuis /Producten/Autosproeikamer/Diesel Bus Paint Booth Truck Paint Box Baking Room

Diesel Bus Paint Booth Truck Paint Box Baking Room

1
MOQ
To be discussed
Prijs
Diesel Bus Paint Booth Truck Paint Box Baking Room
Kenmerken Galerij Productomschrijving Verzoek om een Citaat
Kenmerken
Specificaties
Externe maten (m) Interne maten (m: 12,15 m Lⅹ8,15 m Bⅹ4,6 m H
Interne maten (m: 12m Lⅹ5m Bⅹ4m H
Verwarmingssysteem: Diesel
Capaciteit ((m3/uur): 60000
Totaal vermogen ((KW): 47
geschikte voertuigen: bus.vrachtwagen
Max.Werktemperatuur: 80°C
Opnameventilator: 11 kW * 2 st
Uitlaatventilator: 11 kW * 2 st
Veiligheidsdeur: 2000*800MM
Markeren:

Diesel truck paint booth with baking

,

Bus spray booth with warranty

,

Industrial car paint baking room
Basis informatie
Plaats van herkomst: CHINA
Merknaam: WINTAI
Certificering: CE
Modelnummer: TLSJ-8010
Betalen & Verzenden Algemene voorwaarden
Verpakking Details: Standaard exportverpakking
Levertijd: 25
Betalingscondities: L/c, d/a, d/p, t/t
Levering vermogen: 100
Productomschrijving
Diesel Bus Paint Booth Truck Paint Box Baking Room
Diesel Bus Paint Booth Truck Paint Box Baking Room 0
TELASKA A08 (Standard Specifications)
Component Specification
Booth Cabin Panel High gloss white rock wool panel, thickness 75mm with edges. Color steel plate thickness 0.476mm
Front Door/Safety Door Four sheet metal front doors (4×3.8m) and 2 safety doors (2000×800mm)
Lighting System
Top Lighting 16 sets of LED lights, each set 4×18W
Middle Lighting 16 sets of LED lights, each set 4×18W
Filter System
Ceiling Filter 12 sets of grill type net supporting installation
Intake & Exhaust System
Intake Fan 2 units of European type fan with capacity of 60000m³/h (two sets of intake fans)
Exhaust Fan 2 units of European type fan with capacity of 60000m³/h (two sets of exhaust fans)
VCD Damper 2 units
Load Air Velocity 0.25-0.35 m/s
Exhaust Duct 4 meters of straight duct and 1 piece of 90° bend and 1 piece of 45° bend (2 sets)
Heating System
Heating Method RIELLO brand RG5S diesel burner, cycle heating (2 sets)
Max. Working Temperature 80℃
Constant Temp. Spray Painting Constant Temperature Operation
Control System
Control Panel Made by quality components with the functions of overload, overheat and phase lack protection
Functions Spray, Bake, Lighting and Emergency Stop
Diesel Bus Paint Booth Truck Paint Box Baking Room 1
label:

Verfbooth voor auto's

de cabine van de autoverf

Automobielnevelcabine
